New Arrivals Waterproof Corrugated Little Bule Roofing Sheet For
Park Outdoor Gazebo
Specification of ASA Little Blue Tiles
Thickness | 2.3mm~3.0mm |
Material | ASA + PVC + PCC |
Length | customized(must be according to the times of 219mm) |
Width | 1120MM |
Effect Width | 960MM |
Distance between wave | 250mm | | |
Height of Wave | 40mm | | |
Wave Width | 160mm | | |
Purlin space | 800~1120mm | | |
Weight | 2.5mm: 5.0±0.1kg/m2 | 2.8mm: 5.5±0.1kg/m2 | 3.0mm: 6.0±0.1kg/m2 |
Container Load capacity | Thickness | SQ.M./20 FCL (21 Tons) | SQ.M./40 FCL (26 Tons) |
| 2.5mm | 4000 | 5000 |
| 2.8mm | 3500 | 4300 |
| 3.0mm | 3300 | 4100 |
Features of ASA Little Blue Tiles
(1) Durable color:It can still maintain the stability of its color for over 10 years.
(2) Long lifetime:
It's natural life span can reach more than 30 years, 2-3 times of other roof tile products.
(3) Excellent corrosion resistance:
Resin tile can withstand long-term acid, alkali, salt and other
corrosive chemicals, which is very
suitable for acid rain-prone areas and coastal. its life span is
over 3 times longer than zinc panels.
(4) Heat insulation performance:
The thermal conductivity of synthetic resin tile is 0.325W / (mk),
is about 1/310 of clay tile,
1 / 5 of concrete tile, 1/200 of 0.5mm thickness steel tile.
Applications of ASA Little BlueTiles
Used for flat slope modification project, villas, private house,
mobile housing, garden pavilions, ancient architecture and other
roof areas.
Our factory has rich experience in PVC plastic tile product
manufacture and we are a professional supplier of ASA synthetic
resin tile, Anti-Corrosion APVC roof sheet, Heat Insulated UPVC
roof sheet , PVC corrugated roof sheet , PVC flat sheet , FRP
lighting roof sheet , Transparent PC roof sheet , PVC water gutter
series and accessories.
Why Choose Us
1. More than 10 years experiences in trading and producing
2. Abundant financial strength
3. Good reputation
4. Excellent technique control
5. Rigorous testing process
6. Professional management team
7. With competitive price
8. Meet customers' needs by reprocessing
9. High quality after-sales service
10. Timely delivery time
Test Report
| Test item | Test Standard | Unit | Technical Index |
Heat Resistant Artificial Chromatic Aberration(10000h) | GB/T1644.2-1999 | | ΔE≤4 |
| Charpy Notched Impact Strength Rentention Rate | GB/T1644.2-1999 | % | >60 |
| Exterior Appearance | JC/T562-1994 | | Surface Gloss,No bubbles,Uniform Gloss |
| Impact Performance ( 23℃, 1.5m, 1kg ) | JC/T562-1994 | | Not peel Off |
| Combustion Performance | GB/T8624-1997 | | SDR≤75 (B1) |
Linear Expansion Coefficient | GB/T1036-2008 | 1/℃ | 5×10-5 |
| Thermal Conductivity | GB/T10297-1998 | w/m.k | 0.35 |
Freeze Thaw Resistance | JG149-2003 | | No Cracks ,Hollowing,Surface Bubbles,Peeling Phenomenon On The
Surfaces |
